Eaton Powerware 9355 User Manual

OPERATION
Eaton 9355 UPS (10/15 kVA) User's Guide S 164201594 Rev D www.eaton.com/powerquality
83
The following table shows the basic menu structure.
Table 8. Menu Map for Display Functions
Main Menu Submenu Display Information or Menu Function
UPS Status UPS off / System normal / UPS supporting load / UPS on battery / UPS on
bypass / Active alarm list / Battery status
Event Log Displays up to 127 events and alarms
Measurements
Output L-N and L-L / Current / Frequency / Power
Battery Voltage / Current / Runtime
Input L-N and L-L / Current / Frequency
Bypass L-N and L-L / Frequency
Control
Go to Bypass Mode Transfers the UPS to internal Bypass mode
When this command is active, the option changes to Go to Normal Mode.
Start Battery Test Initiates a battery test
Display Test Four different selectable tests for the front panel functions: the LEDs cycle
through, the alarm beep sounds, the backlight turns off and on, and the
pixels scroll through to test the LCD.
Settings
User Settings See Table 9 for detail.
Service Settings This screen is password-protected.
Identification UPS Type / Part Number / Serial Number / Firmware / Display / CAN Bridge
Turn UPS ON/OFF ON and OFF Options
