TRSM0940 Appendix | Tool Specifications
Tool Specifications
Some repair procedures pictured in this manual show the
use of specialized tools. Their actual use is recommended
as they make transmission repair easier and faster and pre-
vent costly damage to critical parts. For the most
part, ordi-
nary mechanic’s tools such as socket wrenches,
screwdrivers, etc., and
other standard shop items such as a
press, mauls and soft bars are the only tools needed to suc-
cessfully disassemble and reassemble any Eaton®
Fuller®
Transmission.
The following tables list and describe
the typical tools
required to properly service this model transmission above
and beyond the necessary basic wrenches, sockets, screw-
drivers and pry bars.
General Tools
The following general tools are available from several tool
manufacturers such as Snap-On, Mac, OTC and many oth-
ers.
Tool Purpose
0–100 lb-ft (0–135 N•m) 1/2” (12.7 mm) drive Torque
Wrench
General torquing of fasteners [typically 15–80 lb-ft (20–108
N•m)]
0–50 lb-in (0–5.62 N•m) 3/8” (9.52 mm) drive Torque
Wrench
General torquing of fasteners
0–30 lb-in 1/4” drive Torque Wrench Torquing of cap screws to 7 lb-in during Auxiliary Counter Shaft
Bearing endplay
setting procedure
Large Brass Drift 3/4” x 12" (19 mm x 304.8 mm) Protect shafts and bearings during removal
Large Dead Blow Hammer or Maul 32 ounces Provide force for shaft and bearing removal
2 Air Pressure Gauges 0–150 PSI (0–10.34 BAR) Troubleshoot and verify correct operation of air system
Snap Ring Pliers—Large Standard External Remove the snap rings at Auxiliary Drive Gear, Input Shaft Bear-
ing and Counter Shaft Bearings
Feeler Gauges Set Main Shaft washer endplay and Auxiliary Tapered Bearing
endplay
Rolling Head (Crow’s Foot) Pry bar Remove the Auxiliary Drive Gear Bearing
Universal Bushing Driver Remove and install Clutch Housing Bushin
gs. Bushing OD =
1.125", ID = 1.000"
