M.I.B. II (MB Intelligent BiosII)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
M.I.B.II (MB Intelligent BIOS II)
Help Item
Intel (R) Core (TM) i5 CPU 661 @ 3.33GHz
Ratio Status: Unlocked (Min: 09, Max: 25)
Ratio Actual Value: 25
Current Memory Frequency : 1333MHz
Memory Current Type: 9-24-9-9-10-74-5-4-5-20
CPU Vcore : 1.164 V
CPU VTT Voltage : 1.104 V
VDIMM : 1.524 V
PCH Voltage : 1.044 V
Performance Level Standard
DRAM Frequency Auto
Configure DRAM Timing by SPD Auto
Memory Hole Disabled
DRAM Command Rate Auto
CPU Over-clocking Func: Disabled
PCIE Over-clocking Func: Disabled
Spread Spectrum Enabled
Auto Detect DIMM/PCI Clk Enabled
Voltage Function Disabled
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
Auto
800 MHz
1066 MHz
1333 MHz
1600 MHz
Options
DRAM Command Rate (Auto)
This item specifies the rate of the DRAM Command.
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and
we recommend users leave the setting unchanged. Modify it at will may cause the
system to be unstable.
Configure DRAM Timing by SPD (Auto)
When this item is set to enable, the DDR timing is configured using SPD. SPD (Serial
Presence Detect) is located on the memory modules, BIOS reads information coded
in SPD during system boot up.
Memory Hole (Disabled)
This item allows users to enable or disable memory hole remapping.
CPU Over-clocking Func (Disabled)
This item decides the CPU over-clocking function installed in your system. If the
over-clocking fails, please turn off the system power. And then, hold the PageUp key
(similar to the Clear CMOS function) and turn on the power, the BIOS will recover
the safe default.
Performance Level (Standard)
This item shows the performance level of the components, the options are: Standard
and Enhanced.
