4
Introducing the Motherboard
• Intel H55 Express Chipset
• LGA1156 socket for latest Intel
®
Core
TM
i7/Core
TM
i5/Core
TM
i3 processors
• Supports “Hyper-Threading” technology CPU
• DMI 2.5 GT/S
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1333/1066 DDR3 SDRAM
• 1 x PCI Express Gen2 x16 slot
• 1 x PCI Express x4 slot
• 2 x PCI slots
• Supported by Intel H55 Express Chipset
• 5 x Serial ATA 3.0 Gb/s Host Controllers
• ALC892 8-CH High definition audio CODEC
• Realtek RTL8111DL 10/100/1000 Fast Ethernet Controller
• 1 x PS/2 keyboard & PS/2 mouse combo connector
• 1 x SPDIF out port
• 1 x VGA port
• 1 x DVI port
• 6 x USB ports
• 1 x ESATA port
• 2 x RJ45 LAN connectors
• 1 x Audio port (Line in, microphone in and 8-ch line out)
• 1 x 24-pin ATX Power Supply connector & ATX4P connector
• 5 x Serial ATA connectors
• 3 x USB 2.0 headers support additional 6 USB ports
• 1 x Clear CMOS button
• 2 x serial headers
• 1 x parallel header
• 1 x PWR button
• 1 x RST button
• 1 x TPM header
• 1 x Chassis Detect header
• 1 x Front panel header
• 1 x SPDIF out header
• 1 x Front panel audio header
• CPU_FAN/SYS_FAN/PWR_FAN connectors
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 16Mb SPI ROM
• Supports Plug and Play, STR/STD, Hardware moniter, DMI
• F11 hot key for boot up devices option
• CPU voltage adjustable
• Memory voltage adjustable
• Support PgUp clear CMOS hotkey
System BIOS
Form Factor
• Micro ATX Size, 244mm x 244 mm
CPU
Specifications
