ECS H61H2-MV User Manual

H61H2-I5 USER MANUAL
19
Chapter 2
ff
ff
f
Super IO Configuration
Use this item to show the information of the Super IO Configuration.
Super IO Configuration
Super IO Chip IT8758
Serial Port 0Configuration
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main
Advanced Chipset M.I.B III Boot Security Exit
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Set Parameters of Serial Port 0
(COMA)
ff
ff
f
Super IO Chip (IT8758)
This item shows the information of the super IO chip.
fSerial Port 0 Configuration
Scroll to this item and press <Enter> to view the following screen:
Serial Port 0 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Enable or Disable Floppy Disk
Controller
Main Advanced Chipset M.I.B III Boot Security Exit
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Press <Esc> to return to the Super IO Configuration page.
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Serial Port (Enabled)
This item allows you to enable or disable serial port.
Device Settings (IO=3F8h; IRQ=4)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.

ECS H61H2-MV Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Serial port headers	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC, ErP/EuP, WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version	11
Parallel processing technology support	Not supported
BIOS type	AMI
BIOS memory size	64 Mbit
Trial software	Muzee
Bundled software	eBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9

Weight and Dimensions

Depth	170 mm
Width	195 mm
