Chapter 1

H61H2-I5 USER MANUAL

CPU

Specifications

• Intel

H61 Chipset

Chipset

• Dual-channel DDR3 memory architecture

• 2 x 240-pin DDR3 Non-ECC un-buffered DIMM sockets support

up to 16 GB

• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM

Memory

• 1 x PCI Express x16 slot

• Supported by Intel

H61 Express Chipset

- 4 x Serial ATA 3.0Gb/s devices

Expansion Slot

Storage

• 1 x 24-pin ATX Power supply connector

• 1 x 4-pin ATX12V1 Power supply connector

• 1 x 4-pin CPU_FAN connector

• 1 x 3-pin SYS_FAN connector

• 2 x USB 2.0 headers support additional four USB 2.0 ports

• 4 x Serial SATA 3.0Gb/s connectors

• 1 x COM header

• 1 x ME_UNLOCK header

• 1 x Clear CMOS jumper

• 1 x Front Panel USB power select jumper

• 1 x Rear USB/PS2 power select jumper

• 1 x Case open header

• 1 x Front Panel switch/LED header

• 1 x Front Panel audio header

• 1 x Speaker header

• 1 x PS/2 keyboard & PS/2 mouse connectors

• 4 x USB 2.0 ports

• 1 x D-sub (VGA) port (or optional VGA header)

• 1 x RJ45 LAN connector

• 1 x Audio port (line in, microphone in, line out)

Rear Panel I/O

LAN

• Realtek RTL 8111E Gigabit LAN

• Realtek RTL 8105 10/100 LAN (Co-lay)

• VIA VT1705CF 6-Ch High Definition audio CODEC

- Compliant with HD audio specification

Audio

• LGA1155 socket for Intel

Sandy/Ivy Bridge Processors

• DMI 5.0GT/s

• TDP: 65W (up to 77W)

Internal I/O

Connectors &

Headers

Note: Please go to ECS website for the latest CPU support list.

Note: Please go to ECS website for the latest Memory support list.

Questions and Answers:

Need help?

Do you have a question about the ECS H61H2-MV and is the answer not in the manual?

ECS H61H2-MV Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Serial port headers	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC, ErP/EuP, WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version	11
Parallel processing technology support	Not supported
BIOS type	AMI
BIOS memory size	64 Mbit
Trial software	Muzee
Bundled software	eBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9
