39
H61H2-I5 USER MANUAL
Chapter 3
If the auto-install DVD-ROM does not work on your system, you can still install
drivers through the file manager for your OS (for example, Windows Explorer).
Look
for the chipset and motherboard model, and then browse to the directory and path
to begin installing the drivers. Most drivers have a setup program (SETUP.EXE) that
automatically detects your operating system before installation. Other drivers have
the setup program located in the operating system subfolder.
These software(s) are subject to change at anytime without prior notice. Please
refer to the support disk for available software.
Manual Installation
ECS Utility Software (Intelligent EZ Utility)
ECS Intelligent EZ Utility provides friendly interfaces under Windows O.S, which makes
your computing more easily and conveniently.
If the driver you want to install does not have a setup program, browse to the oper-
ating system subfolder and locate the readme text file (README.TXT or README.DOC)
for information on installing the driver or software for your operating system.
Windows 7/8 will appear below UAC (User Account Control) message after the
system restart. You must select “Yes” to install the next driver. Continue this
process to complete the drivers installation.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS H61H2-MV and is the answer not in the manual?

ECS H61H2-MV Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
System bus rate5 GT/s
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Serial port headers1
Number of SATA II connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Supported storage drive interfacesSATA II
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controllerRealtek RTL8111E
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Audio chipRealtek ALC662
CertificationCE/FCC, ErP/EuP, WHCK
Component forPC
Power source typeATX
Motherboard chipsetIntel® H61
Audio output channels6.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version11
Parallel processing technology supportNot supported
BIOS typeAMI
BIOS memory size64 Mbit
Trial softwareMuzee
Bundled softwareeBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9
Weight and Dimensions IconWeight and Dimensions
Depth170 mm
Width195 mm
