ECS H61H2-MV User Manual

H61H2-I5 USER MANUAL
32
Chapter 2
Boot Menu
This page enables you to set the boot device priority.
Boot Configuration
This item shows the information of the boot configuration.
Bootup NumLock State (On)
This item determines if the NumLock key is active or inactive at system start-up
time.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Boot Configuration
Operation System Select [Windows 7 or other OS]
Launch PXE OpROM [Disabled]
Launch Storage OpROM [Enabled]
Fast Boot [Disabled]
Bootup NumLock State [On]
Quiet Boot [Enabled]
Boot mode select [LEGACY]
Set Boot Priority
Boot Option #1 [Hard Disk]
Boot Option #2 [CD/DVD]
Boot Option #3 [USB/Floppy]
Boot Option #4 [USB CD/DVD]
Boot Option #5 [USB Hard Disk]
Boot Option #6 [USB Flash:JetFlashTS4GJFV20 0.00]
Boot Option #7 [Network]
USB Flash Drive Priorities
Boot Option #1/#2/#3/#4/#5/#6/#7/ (Hard Disk / CD/DVD / USB/Floppy / USB CD/DVD
/ USB HardDisk / USB Flash / Network)
These items show the boot priorities.
Main Advanced Chipset M.I.B III Boot Security Exit
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Launch PXE OpROM (Disabled)
Use this item to enable or disable the PXE OpROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Quiet Boot (Enabled)
This item determines if the NumLock key is active or inactive at system start-up
time.
Boot mode select (LEGACY)
Use this item to select boot mode.
Windows 7 or other OS: Boot
policy for Legacy OS
Windows 8: Boot Policy for UEFI
OS without Compatibility Support
Module (CSM)
Manual: User customized CSM
parameters & boot policy
Operation System Select (Windows7 or other OS)
This item is used to select the operation system.
Fast Boot (Disabled)
Use this item to enable or disable the fast boot.
f

ECS H61H2-MV Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Serial port headers	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC, ErP/EuP, WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version	11
Parallel processing technology support	Not supported
BIOS type	AMI
BIOS memory size	64 Mbit
Trial software	Muzee
Bundled software	eBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9

Weight and Dimensions

Depth	170 mm
Width	195 mm
