Chapter 3
H87H3-M4 USER MANUAL
42
PCI Express Configuration
The item in the menu shows the information of PCI Express configuration.
PCI Express 16X Speed (Auto)
This item allows user to configure the PCI Express 16X speed.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Configure PCI Express 16X
Speed B0: D1: F0 Gen1-Gen3
NB PCI Express Configuration
PCI Express 16X
PCI Express 16X Speed Auto
