PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
CPU Temperature (DTS)
This item shows the CPU DTS data for thermal reference.
System Ambient Temperature
This item shows the system Ambient temperature.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU voltage, CPU & system fan speed...etc.
• PCH Temperature
• Vcore Temperature
• CPU Fan Speed
• System Fan Speed
• Vcore
• Vmemory
• + 12.0 V
• + 5.00V
• VCC3
BIOS Setup Utility
CPU Temperature (DTS) : 46
System Ambient Temperature : 30°C/86°F
PCH Temperature : 41
Vcore Temperature : 50
CPU Fan Speed : 1035 RPM
System Fan Speed : N/A
VCore : 1.727 V
Vmemory : 1.496 V
+12.0V : 12.051 V
+5.00V : 5.134 V
VCC3 : 3.412 V
Smart Fan [Enabled]
System Shutdown Temperature
Main Advanced Power Authentication Security Boot Options Exit
Version 2.15.1236. Copyright (C) 2002-2013 American Megatrends, Inc.
+/-/Spacebar : Change Opt.
Enter : Select
F1: General Help
:Move
F2: Previous Values
F3: Optimized Defaults
F4: Save and Exit
ESC: Discard changes and Exit
Setup
Smart Fan (Enabled)
This item shows you to disable/enable the control of the CPU fan speed by changing
the fan voltage.
To Next Page
