25
Using BIOS
Press <Esc> to return to the Standard CMOS Setup page.
Type (Auto)
Use this item to configure the type of the IDE device that you specify. If the feature
is enabled, it will enhance hard disk performance by reading or writing more data
during each transfer.
PIO Mode (Auto)
Use this item to set the PIO mode to enhance hard disk performance by optimizing
the hard disk timing.
DMA Mode (Auto)
DMA capability allows user to improve the transfer-speed and data-integrity for
compatible IDE devices.
IDE BusMaster (Enabled)
This item enables or disables the DMA under DOS mode. We recommend you to leave
this item at the default value.
Press <Esc> to return to the main menu setting page.
Advanced Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced Setup
Help Item
When disabled, force
the XD feature flag to
always return 0.
Intel XD Bit Disabled
TM Status TM1
Limit CPUID MaxVal Disabled
Intel (R) HT Technology Enabled
CPU Host Clock 200MHz
Quick Power on Self Test Enabled
Quiet Boot Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Hard Disk Drive
2nd Boot Device CD/DVD
3rd Boot Device 1st FLOPPY DRIVE
Hard Disk Drives Press Enter
Removable Drives Press Enter
CD/DVD Drivers Press Enter
Boot Other Device Yes
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
ECS eJIFFY Function Disabled
TM Status (TM1)
This item shows TM function status if CPU can support TM function.
Intel XD Bit (Disabled)
This item allows users to enable or disable the Intel XD bit.
Limit CPUID MaxVal (Disabled)
Use this item to enable or disable the Max CPU ID value limit. When supports
Prescott and LGA775 CPUs, enables this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
