32
Using BIOS
Smart Fan Function (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
SMART Fan Function (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status
-=- System Hardware Monitor-=-
Shutdown Temperture Disabled
Smart Fan Function Press Enter
CPU Temperture :72°C/161°F
System Fan Speed : N/A
CPU Fan Speed : N/A
+12.0V : 12.032 V
Vcc : 4.730V
+3.30V : 3.084V
CPU Core : 1.182V
VDIMM : 1.552V
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
Options
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Smart Fan Function Enabled
SMART Fan start PWM value 28
CPU DeltaT +3
SMART Fan start TEMP. (°C) 43
SMART Fan Slope PWM value 5 PWM value/°C
CPU FAN Full Limit Temp(-) 63°C
Disabled
Enabled
Disabled
80°C/176°F
75°C/167°F
70°C/158°F
Press <Esc> to return to the Smart Fan Function page.
Shutdown Temperature (Disabled)
Enable you to set the maximum temperature the system can reach before powering
down.
