ECS TIGD-CI3 User Manual

29
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Integrated Peripherals
SATA Configuration IDE
Onboard SATA Mode Compatible
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 3F8
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
IDE
AHCI
Disabled
Help Item
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: IDE,AHCI,Disabled.
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address (3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Options
Onboard SATA Mode (Compatibe)
Use this item to set SATA mode (not disable )
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a
portaddress.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select Normal
(StandardParallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel
Port), orBPP (Bi-Directional Parallel Port).
ECP Mode DMA Channel (DMA3)
Use this item to assign a DMA channel to the parallel port.
Parallel Port IRQ (IRQ7)
Use this item to assign IRQ to the parallel port.
