SD5/SD6 Ultrasonic TableTop Doppler User Manual EMC Information
- 36 -
A2.2 Electromagnetic Immunity
Guidance and manufacture’s declaration – electromagnetic immunity
The SD5/SD6 is intended for use in the electromagnetic environment specified below. The customer or
the user of SD5/SD6 should assure that it is used in such an environment.
Immunity test IEC 60601 test level
Compliance level
Electromagnetic
environment -guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood,
concrete or ceramic tile. If
floor are covered with
synthetic material, the relative
humidity should be at least
30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±2 kV for power
supply lines
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to line(s)
±2 kV line(s) to earth
±1 kV line(s) to line(s)
±2 kV line(s) to earth
Mains power quality should be
that of a typical commercial or
hospital environment.
Power frequency
(50 Hz/60 Hz)
magnetic field
IEC61000-4-8
3 A/m 3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
<5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT (60% dip in
UT) for 5 cycles
70% UT (30% dip in
UT) for 25 cycles
<5% UT (>95% dip in
UT) for 5s
<5% UT
(>95% dip in UT) for
0.5 cycle
40% UT (60% dip in
UT) for 5 cycles
70% UT (30% dip in
UT) for 25 cycles
<5% UT (>95% dip in
UT) for 5s
Mains power quality should be
that of a typical commercial or
hospital environment. If the
user of the SD5/SD6 requires
continued operation during
power mains interruptions, it is
recommended that the
SD5/SD6 be powered from an
uninterruptible power supply
or a battery.
NOTE UT is the a.c. mains voltage prior to application of the test level.
