Printer Operations

Document ID: OMM-00174 Rev. D Pro 30f Operations Guide 46

The EFI Pro 30f printer has many different resolutions and options for creating bco files for printing at different speeds

and output qualities. With experience the selection of these options will become clearer. When selecting a work flow for

file preparation in the Fiery XF software, be aware that different options result in different printer output speeds and can

have different output qualities as well.

The charts below contain several work flows that EFI has found useful in day to day operation of the EFI Pro 30f printers.

NOTE: Different printer modes have different intended viewing distances for the printed output. In general, the

faster output speeds are intended to be used in creating prints that are viewed from larger distances.

Standard Workflows

6.2 Printing with Fiery XF

Output Mode Up to Sq. Ft (Sq.m)/Hr. Printer Settings

Express 2130 (197.91) CMYK | 300x600 | 1 pass

Distant View/Outdoor 1264 (117.48) CMYK | 600x600 | 2 pass

Production 512 (47.55) CMYK | 600x600 | 6 pass

POP Quality 394 (36.61) CMYK | 600x600 | 8 pass

High Quality 273 (25.37) CMYK | 900x600 | 12 pass

Ultra Quality 166 (15.41) CMYK | 1200x1200 | 24 pass
