Every 40 Hours
Document ID: OMM-00144-L VUTEk 3r & 5r Series Maintenance Guide 39
PPE Items: GLOVES NITRILE DISPOSABLE BOX LARGE
SAFETY GLASSES
Required Items: WIPES 9X9 CLEAN ROOM
ROLL CONDITIONING FLUID
How-to Video:
Directions:
NOTE: Remove all media prior to this procedure.
1. Open the printer hood and insert the retaining pins into
the LH and RH pin sockets.
2. Dampen a lint-free wipe with roll conditioner and
thoroughly wipe down the exposed portion of the
rubber tension roller.
3. From the printer front end, click the Tension (On/Off)
button in the tool bar until unexposed portion is visible.
4. Repeat the wiping and advancing until the entire roller has been wiped clean.
5. Remove the retaining pins after completing tasks.
6.2 Clean the T (Tension) rubber roller.
CLICK TO PLAY
Figure 6-2 Cleaning Tension roller
Figure 6-3 Tension button
