Eizo FlexScan EV2750 User Manual

- 4 -
Notice for this monitor
If the monitor displays continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the
monitor be turned off periodically.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to “Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on the LCD panel, this is not a malfunction.
Percentage of effective dots: 99.9994 % or higher.
The backlight of the LCD panel has a xed lifetime. Depending on the usage pattern, such as usage for long continuous periods, the lifespan of the backlight may
run out sooner, requiring replacement. When the screen becomes dark or begins to icker, please contact your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. If pressure is continually
applied to the panel, it may deteriorate or damage your panel. (If the pressure marks remain on the panel, leave the monitor with a black or white screen. The
symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt to brush with tissues as this may scratch the
panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur on the interior and exterior surfaces of the
monitor. In that case, do not turn the monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the monitor.
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
The stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with water.

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
