Operation
Terminal allocation chart
230 Volt connection
Terminal Description Connector Terminal Description Connector
1 Burner motor phase
4
20 1
st
stage thermostat live (T1)
19
2 Earth 21 Heating request signal (option T2)
3 Neutral 22 Flame monitoring signal
11
41
st
stage solenoid valve live
2
23 Earth
5 Neutral 24 Live
6 Earth 25 Air pressure switch signal
10
7 Live 26 Live
82
nd
stage solenoid valve live 27 Live
20
9 Live L1
6
28 Remote unlocking signal
10 Earth 29 Neutral
21
11 Neutral 30 Signal fault live
12 Earth 31 Live
8
13 Earth 32 Live
14 Igniter live
5
33 Not used
34
15 Earth 34 Not used
16 Neutral
17 Live for the 2
nd
stage thermostat
T6/7/8
18 Signal T7
19 Signal T8
