- ITZAA 25/31 599 38 97-89
7.1.1.1 Replacement of the thermal switches
e) the fan is fitted by means of 2 screws and 1
bracket (remove the fan blade from the fan to
access the screws)
To replace the fan, detach its connector
f) to access to the defrosting heater lift the 3 hooks
up
To replace the defrosting heater, detach its connec-
tor
In case of replacement of the fan, it is necessary to ensure that the fan draws in air.
a) detach the connector 2 (of the thermal switches),
cut the cable (of the thermal switches) and insulate
it with insulating tape
b) detach the connector (of the thermal switches),
cut the cable of the thermal switches and insulate it
with insulating tape
