Emax Nanohawk 1S User Manual

Nanohawk
1
emax-usa.com
Product specification
Product list
1. Nanohawk × 1
2. Instruction manua cardl × 1
3. Emax 1s HV 300 mAh × 1
4. Charger × 1
5. Extra Propeller Set (2x CW, 2x CCW)
6. Screwdriver x 1
7. Spare screws x 1
8. fc damper x 1
9. rubberbands x 1
Nanohawk
Parameter
Diagonal wheelbase (without paddles)
65mm
Maximum size of the aircraft (without
antenna, cable tie)
87×87×30(mm)
Aircraft weight (without battery)
19g
Motor
TH0802II 19000KV
Propeller
Avia Nanohawk 1201-4 Propeller
Main Flight Controller
F4（MATEKF411RX firmware）
4 in one 5A ESC
SPI RX receiver（Compatible with Frsky remote
control D8/D16 mode）
Camera
RunCam Nano 3 Camera
Transmitter
25mW Adjustable frequency 37CH. Support
SmartAudio. Ham radio license required for use in
North America.
Battery
1 Cell 300 mAh HV lipo battery

Emax Nanohawk 1S Specifications

General

Brand	Emax
Model	Nanohawk 1S
Category	Drones
Language	English
