1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 36/41
13.3 AUXILIARY OUTPUT (ixF=AUS)
The AUX output (if present and configured) will be enabled / disabled following the status of the relative
digital input.
13.4 ENERGY SAVING (ixF=ES)
The energy saving mode will be enabled / disabled following the status of the relative digital input.
13.5 EXTERNAL WARNING ALARM (ixF=EAL)
It is used to detect an external alarm. It does not lock the regulation.
13.6 EXTERNAL LOCK ALARM (ixF=bAL)
It is used to detect any critical external alarm. It locks immediately the regulation.
13.7 EXTERNAL PRESSURE ALARM (ixF=PAL)
It is used to detect any pressure external alarm. This signal locks the regulation after detecting nPS events in
the interval dxd.
13.8 EVAPORATOR FAN MODE (ixF=FAn)
It is used to control the evaporator fan.
13.9 REMOTE HOLIDAY MODE (ixF=HdF)
It is used to force the holiday mode.
13.10 REMOTE ONOFF (ixF=onF)
It is used to switch ON and OFF the device remotely.
13.11 LIGHT OUTPUT (ixF=LiG)
It is used to control the light output.
13.12 PULL DOWN (ixF=CC)
It is used to force a cooling cycle.
13.13 MOTION SENSOR DETECTOR (ixF=EMt)
It is used to connect an X-MOD motion sensor. Please note that motion sensor can be connected only to the
HOTKEY port, so digital input 2 must be properly configured.
13.14 CHANGE CONFIGURATION (ixF=MAP)
It is used to change the controller configuration.
14. ALARM SIGNALLING
Label
Cause
Outputs
P1
P1 probe failure
Compressor output according to Con e CoF
P2
P2 probe failure
Depends on the relative function
P3
P3 probe failure
Depends on the relative function
P4
P4 probe failure
Depends on the relative function
HA
High temperature alarm
Outputs unchanged
LA
Low temperature alarm
Outputs unchanged
H2
Second high temperature alarm
Outputs unchanged
L2
Second low temperature alarm
Outputs unchanged
dA
Open door alarm
Compressor and fan follows par. odC
EA
Warning external alarm
Outputs unchanged
CA
Lock external alarm
Outputs disabled
EE
Internal memory alarm
Outputs unchanged
14.1 ALARM RECOVERY
Probe alarms P1, P2, P3 and P4 are activated some seconds after detecting a fault condition in the relative
probe. These alarms are automatically reset some seconds after the relative probe restarts normal operations.
