Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
February 2021
2
Table 1. Specifications
Valve Body Sizes, End Connection Styles, and Port
Diameters
(1)
VALVE
SIZE,
NPS
PORT
DIAMETER,
(INCHES)
THREADED
RAISED FACE
(RF) FLANGED
CL900 CL600
1 0.375, 0.75, 1 X X
2 0.375, 0.75, 1 X X
X = Available construction.
Maximum Inlet Pressures and Temperatures
(1)
VALVE BODY SIZE
MAXIMUM INLET
PRESSURE
TEMPERATURE RANGE
bar (psig) _C (_F)
NPS 1 NPT
CL900
155 (2250) -46 to 93 (-50 to 200)
150 (2185) 93 to 149 (200 to 300)
NPS 2 NPT
CL900
155 (2250) -46 to 93 (-50 to 200)
150 (2185) 93 to 149 (200 to 300)
NPS 1 RF
CL600
103 (1500) -46 to 93 (-50 to 200)
100 (1455) 93 to 149 (200 to 300)
NPS 2 RF
CL600
103 (1500) -46 to 93 (-50 to 200)
100 (1455) 93 to 149 (200 to 300)
Maximum Shutoff Pressure Drops
(1)
MAXIMUM nP BAR (PSI) PER PORT SIZE
Port Size,
mm (inch)
9.5 (0.375) 19.1 (0.75) 25.4 (1.00)
Flow Up 155 (2250) 105 (1518) 75 (1089)
Flow Down 155 (2250) 155 (2250) 130 (1889)
Shutoff Classification per ANSI/FCI 70‐2
and IEC 60534‐4
Class IV
Flow Characteristic / Valve Plug Style
Equal percentage / Micro‐Form Valve Plug
Maximum Travel
15 mm (0.6 inch)
Material Temperature Capabilities
(1)
Valve Body Assembly:
Standard Bonnet O-Ring: -40 to 135°C (-40 to 275°F)
Electric Actuator Assembly: -20 to 70°C
(-4 to 158°F), < 90% non-condensing humidity
Flow Direction
Flow up (standard), Flow down (optional)
Available Actuator Configurations
On/off (snap acting)
Positioning (flow or pressure control)
Power Requirements
9 - 30VDC, minimum 4 amp power supply required
(fuse to 5 amps)
Maximum Current Draw
4 amps
Idle Current Draw
15 mA at 24VDC, 25 mA at 12VDC
Conduit Connections
Two 3/4 NPT connections
Stroke Length
FloPro controlled between 10mm (0.4 inch) and
15mm (0.6 inch)
Nominal Stroke Speed
(2)
3.9 mm/s (0.15 inch/s) at 24 VDC
2.2 mm/s (0.09 inch/s) at 12 VDC
Hazardous Area Approvals
CSA (C/US): ExplosionProof Class I, Division 1,
Groups C and D, T6, Ex d IIA T6, Class I, Zone 1, AEx d
IIA T6
ATEX Flameproof - Gas:
II 2 G, Ex db IIA T6
IECEx Flameproof - Gas: Ex db IIA T6
Enclosure Rating
Type 4X and IP66
Duty Cycle
50% maximum
Enclosure Material
Cast aluminum alloy with powder coat paint
Approximate Weight:
18 - 27 kg (39 - 60 lbs), depending upon construction
1. The pressure or temperature limits in the referenced tables and any applicable ASME code limitations should not be exceeded.
2. 10% variation can be expected, based on temperature and pressure of application.
