Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
February 2021
5
Startup Overview
Figure 2. Flowchart
PREPARE PER INSTRUCTIONS
IN INSTALLATION SECTION
POSITIONING OR
ON/OFF?
POSITIONING
ON/OFF
WIRE PER DIAGRAM FOR L2e
WIRE PER DIAGRAM FOR 4-20 mA
YES
YES
NO
NO
ARE YOU USING
Modbus?
FIRST TIME USING
Modbus?
CONNECT USB-TO-Modbus CONVERTER
TO INTERNET CONNECTED COMPUTER
CONNECT VIA Modbus TO VALVE AND
MONITOR DESIRED REGISTERS
FOLLOW DRIVER INSTALLATION
INSTRUCTIONS FOR YOUR DEVICE
INSTALL easy-Drive CONFIGURATION OR
Modbus MASTER SOFTWARE
uint IS READY FOR OPERATION
