Instruction Manual
D102748X012
DLC3010 Digital Level Controller
Configuration
May 2018
49
Table 4‐4. Burst Variables Sent by the FIELDVUE DLC3010
Burst Option Variable Variable Burst
(1)
Burst Command
Read PV Primary Process variable (EU) 1
Read PV mA and % Range
Loop Current Process variable (mA)
2
Percent Range Process variable Percent range (%)
Read Dynamic Vars
Loop Current Process variable (mA)
3
Primary Process variable (EU)
Secondary Electronics temperature (EU)
Tertiary Process temperature (EU)
Quaternary Not used
1. EU—engineering units; mA—current in milliamperes; %—percent
D Burst Option
1. Select On in the Burst Mode menu; press ENTER to enable Burst Mode.
2. Select the desired option from the Burst Option menu and press ENTER.
3. Press SEND to download the new configuration information to the digital level controller.
For the Field Communicator to be able to communicate with a device whose polling address is not 0, it must be
configured to automatically search for all or specific connected devices.
D Scan Device allows you to refresh the host copy of device configuration.
Instrument Display
Field Communicator Configure > Manual Setup > Instrument Display (2-2-7)
Follow the prompts on the Field Communicator display to view or edit what is visible in the instrument display.
D LCD Configuration— Select this parameter to indicate if the meter is installed. If the meter is physically installed,
select Installed, then send the change to the instrument. When switching the setting from 'Not Installed' to
'Installed', the meter display will be activated immediately. However, if you change the setting to 'Not Installed'
from 'Installed' just to disable the display without physically removing the meter, a device reset or power cycle will
be required before the setting takes effect. The meter must be configured as 'installed' before you can set the
display type or the decimal places.
D Display Mode is only visible if the meter is installed.
D Change Display Mode— Select the type of information the meter should display and how it should be displayed by
selecting 'Change display mode'. You can select for display:
PV displays the process variable (level, interface, or density) in engineering units.
PV/Process Temperature alternately displays the process variable in engineering units, the process temperature in
the units selected under Temp Units (PV Setup), and the degrees of torque tube rotation.
