Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
August 2015
36
An optional local control panel (LCP100), shown in figure 29, can be installed to provide manual operation of the
DVC6200 SIS instrument. Refer to the LCP100 instruction manu
al (D103272X012) for further information.
Note
If the LCP100 is connected to a DVC6200 SIS in a zone 1 explosion-proof “d” environment, there must be a conduit seal installed
between the DVC6200 SIS and the LCP100 in order to maintain the explosion-proof integrity of the DVC6200 SIS.
The LCP100 cannot be connected to a DVC6200 SIS that is part of a zone 0 or zone 1 intrinsically safe “i” installation.
Figure 29. LCP100 Connected to a DVC6200 SIS Instrument
X0248
For de-energize to trip DVC6200 SIS and de-energize to trip solenoid valve, proceed to page 37
For de-energize to trip DVC6200 SIS, no solenoid valve, proceed to page 39
For DVC6200 SIS for PST only and de-energize to trip solenoid valve, proceed to page 41
For solenoid valve health monitoring installations, proceed to page 42
