Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
37
Figure 28. Repair Nameplate (Spaces Provided for Recording Trim Maintenance Data)
GE11233‐B
DATE OF MAINTENANCE
PORT DIAMETER
TRIM MATERIAL
FLOW
CHARACTERISTIC
FLOW CAPACITY
ACTUATOR ACTION
Parts Ordering
Each valve is assigned a serial number which can be found on the valve or on the nameplate (figure 2 and key 35, not
shown). The nameplate will normally be fitted to the actuator. Refer to this serial number when contacting your
Emerson Process Management sales office for technical assistance. When ordering replacement parts refer to this
serial number and give the part description from the following parts list.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Process Management should not,
under any circumstances, be used in any Fisher valve, because they may void your warranty, might adversely affect the
performance of the valve, and could cause personal injury and property damage.
Note
Neither Emerson, Emerson Process Management, nor any of their affiliated entities assumes responsibility for the selection, use, or
maintenance of any product. Responsibility for the selection, use, and maintenance of any product remains with the purchaser and
end user.
