Emerson Fisher GX User Manual

Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
38
Parts Kits
PACKING
KITS
Valve Size
Stem Diameter
DN 25, 40, and 50
(NPS 1, 1‐1/2, and 2)
10 mm
DN 80 and 100
(NPS 3 and 4)
14 mm
DN 150
(NPS 6)
19 mm
PTFE packing (Contains keys 32 and 33) RGXPACKX012 RGXPACKX022 RGXPACKX072
Graphite ULF packing (Contains keys 42, 43, and 44) RGXPACKX052 RGXPACKX042 RGXPACKX082
ACTUATOR
KITS
Actuator Size 225 750 1200
Actuator (Contains keys 10, 19, and 20) RGX225X0012 RGX750X0022 RGX1200X032
BALANCED
SEAL KITS
(1)
Valve Size
DN 80
(NPS 3)
DN 100
(NPS 4)
DN 150
(NPS 6)
Nitrile (Contains keys 37 and 38) RGXSEALX012 RGXSEALX022 RGXSEALX072
Ethylene Propylene (EPDM) (Contains keys 37 and 38) RGXSEALX032 RGXSEALX042 RGXSEALX082
FKM Fluorocarbon (Contains keys 37 and 38) RGXSEALX052 RGXSEALX062 RGXSEALX092
Graphite Piston Ring (Contains key 100) GE26910X012 GE26911X012 GE26912X012
1. A Gasket Kit is required when replacing the seals.
GASKET
KITS
Valve Size
DN 25
(NPS 1)
DN 40
(NPS 1‐1/2)
DN 50
(NPS 2)
DN 80
(NPS 3)
DN 100
(NPS 4)
DN 150
(NPS 6)
Body / Bonnet Gasket Kit
(Graphite Laminate)
(Contains key 5)
GE00077X012 GE00078X012 GE00079X012 GE00080X012 GE00052X012 RGASKETXA62
Body / Bonnet Gasket and
Extension Bonnet Gasket Kit
(Graphite Laminate)
(Contains keys 5 and 47)
RGASKETXA12 RGASKETXA22 RGASKETXA32 RGASKETXA42 RGASKETXA52 ‐ ‐ ‐
REPAIR NAMEPLATE
Description
DN15 to 150
(NPS 1/2 to 6)
18‐8 stainless steel nameplate. Will mount to all GX actuator sizes
using casing bolt. See figure 28.
GE11233X012
BELLOWS
KITS
Description
Valve Size
DN15, 20, 25 (NPS
1/2, 3/4, 1)
DN40
(NPS 1‐1/2)
DN50
(NPS 2)
DN80
(NPS 3)
DN100
(NPS 4)
1.4571 (316Ti) bellows with S31603
extension stem (key 49), graphite laminate
body/bonnet gasket (key 5), graphite
laminate extension bonnet gasket (key 47),
graphite laminate bellows gasket (key 50),
S31603 extension stem insert (key 48),
anti‐extrusion washer (key 32 ‐ quantity of 2);
PTFE packing set (key 33)
RGXBELLX012 RGXBELLX042 RGXBELLX072 RGXBELLX102 RGXBELLX132
N10276 bellows with S31603 extension stem
(key 49), graphite laminate body/bonnet
gasket (key 5), graphite laminate extension
bonnet gasket (key 47), graphite laminate
bellows gasket (key 50), S31603 extension
stem insert (key 48), anti‐extrusion washer
(key 32 ‐ quantity of 2); PTFE packing set (key
33)
RGXBELLX022 RGXBELLX052 RGXBELLX082 RGXBELLX112 RGXBELLX142
N10276 bellows with N06022 extension stem
(key 49), PTFE / N10276 body/bonnet gasket
(key 5), PTFE / N10276 extension bonnet
gasket (key 47), PTFE / N10276 bellows
gasket (key 50), N10276 extension stem
insert (key 48), anti‐extrusion washer (key 32
‐ quantity of 2); PTFE packing set (key 33)
RGXBELLX032 RGXBELLX062 RGXBELLX092 RGXBELLX122 RGXBELLX152
