FloBoss 103/104 Instruction Manual
9-4 Troubleshooting Revised August-2017
6. If the input shows a Point Fail alarm, then the sensor is not
communicating with the FB100.
The DVS contains no user-serviceable or user-replaceable parts. Return
the FB100 to your local sales representative for repair or replacement.
Note: Do not attempt to disconnect the DVS from the FB100. This is a
factory-approved process only.
9.2.7 Pulse Interface Module (FB104)
If your Pulse Interface module is not responding:
1. Start ROCLINK 800, log in, and connect to the FB100.
2. Select Configure > I/O > AI Points.
Select Analog Input 1 or 2. Analog Input 1 is the Meter Pressure;
Analog Input 2 is the Auxiliary pressure. If the Auxiliary pressure is
not installed, this point will show inactive.
Ensure that the Pulse Interface Module is not in manual mode by
setting the Scanning field to Enabled.
3. Go to the Utilities > Pulse Interface Module Data screen in
ROCLINK 800 software and use the diagnostics provided on the
screen. Refer to the ROCLINK 800 Configuration Software User
Manual (Part D301159X012) for more information on this screen.
The Pulse Interface module contains no user-serviceable or user-
replaceable parts. Return the FB100 to your local sales representative
for repair or replacement.
Note: Do not attempt to disconnect the Pulse Interface module from
the FB104. This is a factory-approved process only.
9.2.8 Resistance Temperature Detector
If you are experiencing troubles with the Resistance Temperature
Detector (RTD):
▪ Verify (using ROCLINK 800) that the RTD point is configured as
Analog Input 3.
▪ Verify that the wiring to the RTD terminations is correct. Refer to
Chapter 4.
▪ Verify that the user-supplied RTD probe is not faulty. Refer to the
instructions that accompanied the RTD probe.
The RTD contains no user-serviceable or user-replaceable parts. If you
are certain that the RTD is not at fault, teturn the FB100 to your local
sales representative for repair or replacement.
