Emerson LC320EM8 Service Manual

4-1 A71F3DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
N = Nut, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Table."
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1]
Stand Base
Plate
D1 4(S-1), 6(S-2), 5(S-3) ---
[2]
Stand
Hinge
D1 --------------- ---
[3]
Stand
Cover
D1 --------------- ---
[4]
Rear
Cabinet
D1 10(S-4), 4(S-5) ---
[5]
Function
CBA
D1
D5
3(S-6), *CN3002 ---
[6]
Chassis
Bracket
D2 8(S-7) ---
[7]
Power
Supply
CBA
D2
D5
4(S-8), *CN101B,
*CN501, *CN801,
*CN802, *CN3010,
*CN3014
---
[8]
Jack
Holder(D)
D2 (S-9), (S-10), (N-1) ---
[9] Shield Box D2
5(S-11), *CN3001,
Shield Plate
---
[2] Stand Hinge[11] Jack CBA
[17] IR Sensor
CBA
[5] Function CBA
[3] Stand Cover
[7] Power Supply
CBA
[15] T-CON CBA
[1] Stand Base
Plate
[4] Rear Cabinet
[6] Chassis Bracket
[12] Inverter CBA
[13] Junction CBA
[9] Shield Box
[14] Panel Holder
[19] Front Cabinet
[10] Digital Main
CBA Unit
[16] LCD
Module Assembly
[8] Jack Holder(D)
[18] Speaker(s)
[10]
Digital Main
CBA Unit
D2
D5
*CN3018, *CN3023 ---
[11] Jack CBA
D3
D5
5(S-12) ---
[12]
Inverter
CBA
D3
D5
6(S-13), *CN1050,
*CN1100, *CN1150,
*CN1200, *CN1250,
*CN1300
---
[13]
Junction
CBA
D3
D5
Desolder ---
[14]
Panel
Holder
D3 8(S-14), 2(S-15) ---
[15]
T-CON
CBA
D4
D5
6(S-16), Shield Plate,
*CN9001, *CN9002,
*CN9005
---
[16]
LCD
Module
Assembly
D4 6(S-17) ---
[17]
IR Sensor
CBA
D4
D5
2(S-18) ---
[18] Speaker(s) D4 8(S-19) ---
[19]
Front
Cabinet
D4 --------------- ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
