Emerson LC320EM8 Service Manual

20070424 13-1 A71F3EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
LCD MODULE ASSEMBLY
*VCOM Adjustment and White Balance Adjustment
are required when reparing T-CON CBA.
DIGITAL MAIN CBA UNIT
MPS CBA
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
LCD MODULE ASSEMBLY
Consists of the following:
UF320XA
T-CON CBA
CELL ACF ASSEMBLY
BACKLIGHT ASSEMBLY
1FSA10238
----------
----------
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT 1ESA14492
Ref. No. Description Part No.
MPS CBA
Consists of the following
1ESA14489
POWER SUPPLY CBA(MPS-1)
FUNCTION CBA(MPS-2)
IR SENSOR CBA(MPS-3)
JACK CBA(MPS-4)
----------
----------
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA(MPS-1)
Consists of the following:
----------
CAPACITORS
C601# ALMINIUM ELECTROLYTIC CAP 150µF/200V CA2D151NC236
C602 CERAMIC CAP. R K 680pF/2KV(HR) CCD3DKA0R681
C604 FILM CAP.(P) 0.033µF/50V J CA1J333MS029
C605 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
C606 FILM CAP.(P) 0.1µF/50V J CA1J104MS029
C608 SAFETY CAP. 4700pF/250V CCD2EMA0E472
C633 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZNDL102
C634 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 CE1AMZNDL472
C635 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
C636 CERAMIC CAP. R K 1500pF/2KV(HR) CCD3DKA0R152
C638 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 CE1AMZNDL472
C639 ELECTROLYTIC CAP. 1000µF/50V M CE1JMZPDL102
C640 ELECTROLYTIC CAP. 22µF/16V M CE1CMASDL220
C642 CAP ELE STD-85 4700µF 6.3V SL CE0KMZNDL472
C643 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 CE1AMZNDL472
C644 ELECTROLYTIC CAP. 1000µF/16V M CA1C102SP085
C647 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C648 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZNDL102
C649 ELECTROLYTIC CAP. 220µF/25V M CE1EMASDL221
C650 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C652 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C653 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C654 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 CE1AMZNDL472
C655 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C656 CAP ELE STD-85 4700µF 6.3V SL CE0KMZNDL472
C657 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C658 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C659 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C660 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C661 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C662 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C663 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C664 CAP ELE STD-85 4700µF 6.3V SL CE0KMZNDL472
C665 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C801 ELECTROLYTIC CAP. 100µF/16V M CA1C101SP085
C802 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C803 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C804 ELECTROLYTIC CAP. 100µF/16V M CA1C101SP085
C805 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C806 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C807 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C808 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
C809 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C810 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C811 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZNDL102
C812 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C813 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C814 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C815 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C816 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C817 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C818 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C819 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C821 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
C823 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C824 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C825 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C826 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C827 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
C833 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C834 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C835 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C842 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C843 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C851 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C857 ELECTROLYTIC CAP. 100µF/16V M CA1C101SP085
C859 ELECTROLYTIC CAP. 47µF/16V M CA1C470SP085
C860 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C861 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C862 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
C863 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
Ref. No. Description Part No.
