Emerson LC320EM8 Service Manual

20070424 12-1 A71F3CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A71F3UH 1EM021693
A2 BRAND BADGE L L5002UC 1EM423715
A3 CONTROL PLATE A71F3UH 1EM322558
A4 REAR CABINET A71F3UH 1EM021694
A5 DECORATION PLATE A71F3UH 1EM021730
A6# RATING LABEL A71F3UH ----------
A7 FUNCTION KNOB A71F3UH 1EM121856
A9 STAND COVER L4301UB 1EM221344A
A10 REAR COVER A71F3UH 1EM322611
A12 STAND RUBBER FOOT L5001CB 1EM423855
A14 JACK PLATE A71F3UH 1EM221569
B1 PANEL HOLDER 32V A71F0UH 1EM121831
B3 SHIELD BOX A71F0UH 1EM121832
B4 CHASSIS BRACKET 32V A71F0UH 1EM121806
B6 JACK HOLDER(D) A71F3UH 1EM221570
B7 STAND BASE PLATE L4300UA 1EM121113A
B8 STAND HINGE A71F3UH 1EM221560
B13 GRAND TAPE L4300UA 1EM423095
B16 CLOTH(10X180XT0.5) L0336JG 0EM408827
B17 CLOTH 10X150XT1.0 1EM421092
B18 CLOTH(15X30XT1.0) B7507UH 0EM402452
B19 CLOTH(20X65XT0.5) L0100JA 0EM407914
B20 GASKET A71F0UH 1EM424393
B29 SHIELD PLATE A71F0UH 1EM322609
B32 GRAND TAPE (TR-19) A71F0UH 1EM424512
B33 RUBBER CUSHION (10X10X13) A71F0UH 1EM424527
B34 RUBBER CUSHION (10X10X20) A71F0UH 1EM424528
B40 RUBBER CUSHION (10X15X10) A71F3UH 1EM424529
CL3023 WIRE ASSEMBLY 101 30PIN / 70MM WX1A71F0-101
CL7501 WIRE ASSEMBLY 102 24PIN / 430MM WX1A71F0-102
CLN101 WIRE ASSEMBLY 003 8PIN / 250MM / AWG26 WX1A71F3-003
CLN102 WIRE ASSEMBLY 002 6PIN / 185MM / AWG26 WX1A71F3-002
CLN801 WIRE ASSEMBLY 006 2PIN / 440MM / AWG22 WX1A71F3-006
CLN802 WIRE ASSEMBLY 005 2PIN / 220MM / AWG22 WX1A71F3-005
FIL101 CLAMP FILTER ZCAT1518-0730 XL03022TE001
L1 SCREW P-TIGHT 4X14 BIND HEAD GBJP4140
L2 SCREW P-TIGHT M4X14 PAN HEAD+BLK GPHP4140
L3 SCREW P-TIGHT M3X12 DISH HEAD+ GDJP3120
L4 SCREW P-TIGHT 3X10 BIND HEAD+ GBJP3100
L7 SCREW B-TIGHT 3X10 BIND HEAD+ BLK GBHB3100
L9 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L11 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L12 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L13 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L15 NUT 3/8-32UNEF 0EM401451A
L16 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392
L18 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
SP801 SPEAKER MAGNETIC S0516F13 DSD1612XQ002
SP802 SPEAKER MAGNETIC S0516F13 DSD1612XQ002
PACKING
S1 CARTON A71F3UH 1EM322559
S2 STYROFOAM TOP A71F3UH 1EM021697
S3 STYROFOAM BOTTOM A71F3UH 1EM021698
S4 SET BAG L4300UA 1EM321546
S5 RFID LABEL P7100UM ----------
S6 STAND SHEET L5001CB 1EM423856
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A71F3UH 1EMN22139
X3 REMOTE CONTROL NF015UD 170/
ECNLC501/NF015UD
NF015UD
X4 DRY BATTERY(SUNRISE) R6SSE/2S XB0M451MS002
Ref. No. Description Part No.
