Emerson Liebert NX User Manual

Battery Installation
21
Figure 10 Battery cabinet internal layout
Minimum Service Space 65mm
3 Layers:
Largest Battery Dimensions:
201x170x190 (LxWxH)
Positions of Captive Nuts
for Grille Mounting
1 Layer:
Largest Battery Dimensions:
201x170x190 (LxWxH)
Captive Nut M6
Hex Flange
Screw M6x16
1.
15
29
43
DETAIL B
B
215 280 280 280 292
65
65 65 102
201 10 201 10 2017
635
738
15170101701017010170
520110201218
517010170
368
635
308,6 280 280 328,4
437,8
218,5
