February 2019
2
Quick Start Guide
NOTICE
This guide provides basic guidelines for Rosemount 520 Level Transmitters. It does not provide instructions
for configuration, diagnostics, maintenance, service, troubleshooting, or Intrinsically safe installations. Refer
to the Rosemount 520 Reference Manual for more information.This manual is also available electronically on
Emerson.com/Rosemount
.
Explosions could result in death or serious injury.
Installation of this transmitter in hazardous areas must be in accordance with the appropriate local, national,
and international standards, codes, and practices. Review approvals section of the Rosemount 520 Reference
Manual for any restrictions associated with a safe installation.
Before connecting a HART
®
-based communicator in an explosive atmosphere, make sure the instruments in
the loop are installed in accordance with intrinsically safe or non-incentive field wiring practices.
Electrical shock can result in death or serious injury.
Avoid contract with the leads and the terminals. High voltage that may be present on leads can cause
electrical shock.
Contents
System readiness . . . . . . . . . . . . . . . . . . . . . . . . . 3
Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mount the transmitter . . . . . . . . . . . . . . . . . . . . 4
Connect wiring and power up . . . . . . . . . . . . . 13
Verify transmitter configuration (optional) . 16
Trim the transmitter (optional) . . . . . . . . . . . . 17
Product Certifications . . . . . . . . . . . . . . . . . . . . 18
