Using LANVIEW
4-2 Troubleshooting
Using LANVIEW
TheA2H254‐16supportstheEnterasysNetworksbuilt‐inLANVIEWLEDvisual
diagnosticandstatusmonitoringsystem.TheLANVIEWLEDsontheA2H254‐16are
locatedasshownin
Figure4‐1.TheseLEDsallowyoutoquicklyobservenetworkstatus
fordiagnosingswitchandnetworkproblems.
Figure 4-1 LANVIEW LEDs of A2H254-16
1 Recessed Password Reset Button 5 Link/Activity for Ethernet Ports 1-16
2 Redundant Power Supply Active 6 1000 Mbps Stacking Port Link/Activity
3 Unit selected as Stack Manager 7 MGBIC Link/Activity
4 CPU and Power Indicator
Note: The terms flashing, blinking, and solid used in Table 4-1 indicate the following:
Flashing: LED is flashing randomly.
Blinking: LED is flashing at a steady rate (approximately 50% on, 50% off).
Solid: LED is on steady and not pulsing.
