Episode ECA-70MIXAMP-1-240 User Manual

pg. 12
ECA-70MIXAMP-1-240 Installation Manual
Specications
Rated Power Output 240 watts
4 Microphone Inputs ±2.5mV/2KΩ XLR balanced with phantom power
Phantom Power +48v
Input Sensitivity/Impedance Source 1:350mV/47kΩ
Source 2:350mV/47kΩ
Source 3:350mV/47kΩ
Source 4:350mV/47kΩ
Signal To Noise Ratio >73dB
Frequency Response 70Hz-16KHz +1,-3dB)
Control
Bass ±10dB
Treble ±10dB
Chime 2 and 4 tone options
Output Sensitivity /Impedance 1000mV/470Ω
Output Rec/Impedance 200mV/470Ω
Distortion <0.1%
Operating Condition
AC Mains Input 120V AC, 24V DC(Optional)
Dimensions (D x W x H) 19x14.3x3.5
Power Consumption 480 watts
Weight 36.4 Ibs
