a
• Auto V-Keystone works only when Projection is set to Front from
the Configuration menu.
s Extended - Projection p.61
• If you do not want to enable Auto V-Keystone, set Auto V-
Keystone or Auto Keystone to Off.
s Settings - Keystone - H/V-Keystone - Auto V-Keystone
p.59
s Settings - Auto Keystone p.59
Correcting manually
You can manually correct keystone distortion.
• You can use V-Keystone to correct the projected image under the
following conditions.
Correction angle: approx. 30˚ up and down
• You can use H/V-Keystone to correct the projected image under the
following conditions. (EB-X14G only)
Correction angle: approx 30˚ right and left/approx. 30˚ up and down
V-Keystone (EB-W02/EB-X02/EB-S02/EB-W01/EB-S01 only)
Press the [w] or [v] buttons on the control panel.
a
You can also set V-Keystone from the Configuration menu.
s Settings - Keystone p.59
H/V-Keystone (EB-X14G only)
Manually correct distortion in the horizontal and vertical directions
independently.
a
Press the [w] or [v] buttons on the control panel during
projection to display the Keystone screen.
b
Press the following buttons to correct keystone distortion.
Press the [
w] or [v] buttons to correct vertical distortion.
Adjusting Projected Images
33
