Epson EH-TW5500 User Manual

7
Part Names and Functions
Remote control
• Remote control light-emitting area p.13
Outputs remote control signals.
• Power button p.14 , 15
Turns the projector power on/off.
• Memory button p.24
Saves, loads, and erases memory
contents.
• Default button p.26
Returns settings of the adjustment
screen in the configuration menu to
their default values when pressed
while displaying the screen.
• Enter/Line menu button
p.18, 24
, 26
Displays the line menu.
While viewing a menu, press this
button to select the menu item and
proceed to the next display.
•
button
p.18, 20, 22, 26
Press to select menu items and
adjustment values.
• Gamma button p.20
Adjusts the gamma.
• Sharpness button p.23
Adjusts the image sharpness.
• Blank button p.26
Turns off and on the projected
images temporarily.
When pressed while the
configuration menu is displayed,
or while a menu is displayed by
pressing , ,
, or , the menu
screen disappears and appears.
• Illumination button
Illuminates all of the buttons on the
remote control for 10 seconds so
that they can be seen in dark
places.
• Color Mode button p.18
Changes the color mode to suit the
projection environment.
• Aspect button p.18
Changes the aspect ratio to match
the input signal.
• Esc button
p.18
, 20 , 26
Returns to the previous menu when
pressed while displaying the menu.
Switches the input source to the
input terminals indicated on each
button.
• Pattern button p.17
Displays and clears the test pattern.
• RGBCMY button p.20
Adjusts the hue, saturation and
brightness for each RGBCMY
color.
• Menu button p.26
Displays and closes the full
configuration menus.
Source buttons p.15
