Supported Media
The following media can be used with the printer.
Print quality is greatly affected by the type and quality
of media used. Choose a media suited to the task at
hand. For information on use, refer to the
documentation supplied with the media or contact the
manufacturer. Before buying media in large
quantities, try printing on a smaller sample and check
the results.
Caution:
Because the media is heavy, it should not be
carried by one person.
We recommend using a lifter for media that
weighs over 40 kg.
c
Important:
Do not use media that is wrinkled, scuffed, torn,
or dirty.
Roll media
Roll core size 2 or 3 inch
Roll outer diameter Up to 250 mm
Media width 300 to 1626 mm (64 inch)
Media thickness 0.04 mm to 1.00 mm
Roll weight
Maximum 45 kg
*
* The specifications for lifters that can be used to load media
that weighs over 40 kg are as follows.
• Thickness of the fork and table: under 28 mm
• The surface of the fork and table can be lowered
approximately 190 mm from the floor.
Moving and Transporting
the Printer
This section describes how to move and transport the
product.
Moving the Printer
This section assumes that the product is being moved
to another location on the same floor without
traversing stairs, ramps, or lifts. See below for
information on moving the printer between floors or
to another building.
U “Transport” on page 120
Caution:
Do not tilt the product more than 10 degrees
forward or back while moving it. Failure to
observe this precaution could result in the printer
falling over, causing accidents.
Getting Ready
A
Confirm that the printer is off.
B
Remove the Waste Ink Bottle.
U “Replacing the Waste Ink Bottle” on
page 74
C
Disconnect the power cords and all other cables.
D
Remove media from the Media Feeding Unit
and Auto Take-up Reel Unit.
SC-F9300 Series User's Guide
Appendix
119
