Epson TM-m30II-NT User Manual

71
Chapter 3 Advanced Usage
Printing a Status Sheet
Follow the steps below to check the interface settings.
Using the Status Sheet Button
1
Check that the printer is turned on.
Make sure the roll paper cover is closed.
2
If there is a bottom cover, remove the cover.
See "Removing the Covers" on page 95 for details on removing the bottom cover.
3
Hold down the status sheet button for at least three seconds.
The status sheet is printed. After printing, the printer returns to the standard mode.
Using the Feed button
1
Check that the printer is on.
2
Open the roll paper cover.
3
Hold down the Feed button for at least one second.
4
Close the roll paper cover.
The status sheet is printed. After printing, the printer returns to the standard mode.
You cannot print after turning on the power while the Power LED is flashing.
• After the status sheet is printed, only the print settings of the mainly connected interface are
retained. For the mainly connected interface, see "Printing Using Multiple Interfaces" on page
28.
• Ether
net and Wi-Fi status sheets are not printed while the printing communication protocol is
being established. They will be printed after the connection is cut off (including being cut due to
a time out).
• "(none)" is printed for the "Connected Peripheral" if no peripherals are connected to the USB
downstream port connector.

Epson TM-m30II-NT Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	2.2 million cuts
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Power plug type	Type C
Power source type	AC
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
USB connector	USB Type-A / USB Type-B
Serial interface	No
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	195 mm
Package height	235 mm
Package weight	2382 g
Quantity per pack	1 pc(s)
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
