Epson TM-m30II-NT User Manual

91
Chapter 5 Handling
Removing Jammed Paper
Follow the steps below if the roll paper is jammed.
1
Turn off the printer
2
Open the roll paper cover.
3
Remove the jammed paper.
4
Close the covers.
Do not touch the thermal head and its surroundings. After printing, the thermal head and its
surroundings can be very hot.
CAUTION
When a paper jam occurs, never pull out the paper forcibly.

Epson TM-m30II-NT Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Built-in barcodes	-
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	2.2 million cuts
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Built-in sensors details	Paper End Sensor, Papier-Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Power plug type	Type C
Power source type	AC
Maximum roll diameter	83 mm
Supported paper width	58 mm - 80 mm (Breite) mm
USB connector	USB Type-A / USB Type-B
Serial interface	No
USB 2.0 ports quantity	2
Connectivity technology	Wired
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	240 mm
Package width	195 mm
Package height	235 mm
Package weight	2382 g
Quantity per pack	1 pc(s)
Print head life	150.000.000 Impulse
Mean cycles between failures (MCBF)	65000000
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Width	127 mm
