Examples Example with heating pipeline
5.2.4 Showing terminal assignments
Showing and connecting terminal allocation
All configured function blocks for the individual circuit
boards are listed in the [Selected FUBs] window. When
you select a function block, its assigned terminal
allocation is shown in the window below.
Connect the individual components to the respective
terminals on the circuit board. Once all components
have been connected, press the [Next] button to
continue configuration.
You can also change the assignment of a
terminal, see 3.3 "
Modify terminal assignment".
5.2.5 Installing a configuration
Installing a configuration
Finish by pressing [Apply] to install the configuration.
The configuration will then be adopted and the
software restarted.
5.2.6 Resuming commissioning
Continue heating system commissioning
Continue to commission the heating system and
perform a function test of components such as pumps,
mixing valves, temperature sensors, etc.
Next, make customer-specific adjustments to the
control system such as hot water temperatures, buffer
charging time slots, heating time slots and room tem-
peratures...
The required parameters are listed in Chapter 6 "
Con-
figuration parameter".
Making a backup after commissioning
Back up the configuration straight away after you have
adapted the heating system to suit the customer's re-
quirements. See Chapter 4 "
Backing up and restoring
a configuration".
