5
0
1
2
3
4
0
1
2
3
4
S1
S2
Stitch width dial
/Disco para puntada
Stitch length dial
/Disco de longitud de puntada
5 4 3 2 1 0
4
3
2 1
0.5
1 2
Turn the stitch selection dial to "B"
Function of zigzag dial
The maximum zigzag stitch width for zigzag stitching is "5",
however, the width can be reduced on any patterns. The width
increases as you move zigzag dial from "0" to "5". For twin needle
sewing, never set the width wider than "3". (1)
Function of stitch length dial while zigzaging
The density of zigzag stitches increase as the setting of stitch
length dial approaches "0".
Neat zigzag stitches are usually achieved at "2.5"or below. (2)
Closed up zigzag stitches (close together) are referred to as a
satin stitch.
Cose la puntada de zigzag
Puntada de zigzag manual tienen tres postura diferentes, e stos
envuelven la postura del disco del ancho de la costura y la longitud
de la costura manual.
25
