1 2
3
Attention:
Disconnect the machine from the electricity supply by removing the
plug from the mains socket. When cleaning the machine, it must
always be disconnected from the electricity supply.
Remove the stitch plate:
Turn the handwheel until the needle is fully raised. Open the hinged
front cover and unscrew the needle plate screw withe the screw
driver.(1)
Cleaning the feed dog:
Remove the bobbin case and use the brush supplied to clean the whole
area.(2)
Cleaning and lubricating the hook:
Remove the bobbin case. Snap the two hook retaining arms (3)
outwards. Remove the hook race cover (4) and the hook (5) and clean
withe a soft cloth. Lubricate at the points (6) (1-2 drops) with sewing
machine oil. Turn the handwheel until the hook race (7) is in the left
position. Replace the hook (5). Replace the hook race cover and snap
back the two hook retaining arms. Insert he bobbin case and bobbin
and replace the stitch plate.
Important:
Fabric fluff and threads must be removed regularly. Your machine
should be serviced at regular intervals at one of our service agencies.
46
4
5
6
7
3
