17
FCC2
FCC2
14 15 16 17 18 19
---
+24V
++
-TX
FSW
20 21
W.L.
LOCK
J5
J6
22
23
24 25
FCA1
FCC1
FCA2
FCC2
!
F
Fig. 18
Fig. 19
Fig. 20
*
*
*
The following table shows the sequence of functions accessible
in BASIC PROGRAMMING:
BASIC PROGRAMMING
Display Function Default
= Semi-automatic
= Automatic
= "Safety" Automatic
= "Stepped" Semi-automatic
= "Stepped" Automatic
= "Safety Stepped" Automatic
= "B" Semi-automatic
= Dead-man
PAUSE TIME:
This has effect only if the automatic logic
was selected. Adjustable from
to
sec. in one-second steps.
Subsequently, display changes to
minutes and tens of seconds (separated
by a point) and time is adjusted in 10-
second steps, up to the maximum value
of
minutes.
E.g. if the display shows
, pause time
is 2 min. and 50 sec.
LEAF 1 FORCE :
Adjusts thrust of Motor 1.
= minimum force
= maximum force (hydraulic)
Exit from programming and return to
display of inputs status.
4.7. TERMINAL BOARD J6 - LIMIT-SWITCHES AND/OR
GATECODER (FIG.2)
These inputs are designed for connection of opening and
closing limit-switches which, according to type of programming
- can command either leaf stop or start of deceleration.
Unconnected limit-switches must be jumper connected (if no
limit-switch is connected, there is no need to make jumpers).
Gatecoders can also be used to detect the leaf's angular
position and to thus obtain deceleration and stop positions
independent of work time.
Limit-switches and Gatecoders can also be used in combination
to stop movement before the mechanical stop limit is reached.
To wire, see fig. 18, 19 and 20.
FCA1 - Leaf 1 opening limit-switch
FCC1 - Leaf 1 closing limit-switch
FCA2 - Leaf 2 opening limit-switch
FCC2 - Leaf 2 closing limit-switch
N.B.:Maximum configurations are shown on the drawings.
All intermediate configurations are allowed, using only
some elements (only 1 Gatecoder, only 1 limit-switch, 2
Gatecoders and 2 limit-switches etc.).In this case, the
unused inputs must be jumpered to earth
5. PROGRAMMING
To program operation of the automated system, you have to
access the "
PROGRAMMING
" mode.
Programming is split into two parts:
BASIC
and
ADVANCED
.
5.1. BASIC PROGRAMMING
To access BASIC PROGRAMMING, press key F:
•if you press it (and hold it down), the display shows the name
of the first function.
•if you release the key, the display shows the value of the
function that can be modified with keys + and -.
•if you press F again (and hold it down), the display shows the
name of the next function, etc.
•when you reach the last function, press F to exit the program,
and the display resumes showing the status of the inputs.
LEAF 2 FORCE :
Adjusts thrust of Motor 2.
= minimum force
= maximum force (hydraulic)
LEAF 1 CLOSING DELAY:
Delays closing start of leaf 1 with respect to
leaf 2. Adjustable from
to minutes
(see Pause Time).
TIME LEARNING (see Chapter 6.3.):
Enables the selection between "simple"
(automatic) learning and "complete"
(manual choice of deceleration and stop
points) learning.
!
+
앓앓
앓앓
앓
1 s.
Simple learning:
!
+
>
3 s.
Complete learning:
RED
RED
BLACK
BLACK
WHITE
WHITE
RED
RED
BLACK
BLACK
WHITE
WHITE
FUNCTION LOGICS (see tab. 3/a - h):
NB.:
if you are using hydraulic operators, set force to maximum
level.
