Pag. 59
Technical
CONNECTING TO A MONITOR
CONECTING TO A TELEPHONE
41 2 3 6
Activation of additional lights or bells
USE
For places with a lot of background noise (factories, shows, etc.) in which the normal call tone cannot be heard or to
help people with hearing difficulties.
MATERIAL NEEDED
Light activator Ref. 8053.
OBSERVATIONS
Any item which works off the mains supply, maximum consumption 2 A (400 watts if using the 220 supply ) can be
connected to the outlet of this equipment.
CONNECTING TO A MONITOR
CONECTING TO A TELEPHONE
110 - 240Vac
2AF1
Red
34
4123 6
ACTIVADOR DE LUCES
LIGHT COMMANDER
REF. 8053
50ö60Hz
110ö240Vac
43
Max. 2A
2A.
Connection of a call extension
USE
Allows us to hear the telephone or monitor call tone when we are in a different place to where it is installed.
MATERIAL NEDED
Call Extension Ref. 2040.
COMPLEMENTARY INSTALLATIONS
CONECTING TO A MONITOR
TELEPHONE
ELECTRONIC CALL
EXTENSION
TO THE GENERAL
INSTALLATION
TO THE GENERAL INSTALLATION
