427-0075-01-12 Revision 140 October 2019 24
This document does not contain any export-controlled information.
Basic Operation and Configuration
2.3.1 Live Video Page
The Live Video page displays a live image from the camera on the left part of the screen. Along the
top of the screen are some menu choices, including Live Video (the red text indicates it is selected),
Help and Log out.
On the right side are control buttons and a virtual joystick (for pan/tilt capability).
In the lower right corner of the web page there is a frame rate selector. This selector allows the user
to change the rate at which the frames are displayed in the browser from the default 8 fps up to 16
fps. This controls the frame rate of the user’s own web browser only, and does not affect the video
streams to other users or to an NVR. If the live video is not displayed, refer to
.
Help
The menu displays software version information. If it is necessary to contact FLIR Technical
Support for assistance, it will be helpful to have the information from this page on hand. For
information about the camera including hardware part numbers and serial numbers refer to the
Maintenance > Product Info > Identification web page (requires Admin login).
Log out
Use this button to disconnect from the camera and stop the display of the video stream. If a web
session is inactive for 20 minutes, it will be stopped and it will be necessary to log in again.
Toggle PC/Camera time
Use this button to display either the PC time or the camera time.
Figure 2-1: Live Video Web Page – user login
Toggle Time
