Force FS 1000 User Manual

25
Item
Qty
Description
13
1
C Rail - Steel
14
1
Chain Connector
15
2
Threaded Shaft
16
1
Pivot Pin
17
1
Chain Wheel
18
1
Track Ending Bracket
19
1
Wall Bracket
20
1
Straight Arm
21
1
Door Bracket
22
1
Bent Arm
23
2
Transmitter
24
1
Transmitter Bracket
Item
Qty
Description
25
1
Trolley Assy
26
2
POM Protective Cover
27
1
Chain
28
1
Release Handle
Item
Qty
Description
1
1
LED Light Cover
2
1
Control Panel Cover
3
1
PCB(1)
4
1
Opener Middle Cover
5
1
DC Gear Motor
6
1
Motor Shaft Sleeve
7
1
PCB(2)
8
1
Steel Bottom Base
9
1
Sprocket bearing base
10
1
Transformer
11
1
Transformer Plate
12
2
Mounting Bracket
2
18
17
16
15
12
14
13
20
9
9
26
8
21
7
22
27
23
24
25
11
10
6
5
4
3
28
1
PARTS LISTING FOR T-RAIL OPENER
