Amber - 2 metres (79 inches)D
Amber - centre line of the
projected vehicle path
E
Note:
When reversing with a trailer, the
lines on the screen are not shown. The
camera will show the vehicle direction and
not the trailer.
Deactivating the rear view
camera
Note:
Disengage reverse gear. The
display will stay on for a short period
before switching off.
Note:
The system will automatically
switch off once the vehicle speed has
reached approximately 15 km/h (9 mph).
Press the parking aid switch in the
instrument panel. For item location: See
Quick start (page 10).
Vehicles with parking aid
The display will additionally show a
coloured distance bar. This guide
indicates the distance from the rear
bumper to the detected obstacle.
These are colour coded as follows:
•
Green - 0.8 to 1.5 metres (31 to 59
inches).
•
Amber - 0.3 to 0.8 metre (12 to 31
inches).
•
Red - 0.3 metre (12 inches) or less.
159
Rear view camera
