Protected componentsFuse amp ratingFuse or relay number

Not used.–86

Anti-lock brake system pump.

60A

M-type fuse.

J-type fuse.

Passenger Compartment Fuse

Panel

The fuse panel is located under the

instrument panel to the left of the steering

column.

Note: It may be easier to access the fuse

panel if you remove the finish trim piece.

E145984

243

Fusion/Mondeo (CC7) Canada/United States of America, enUSA, First Printing
