E145779
4. Turn the bulb holder counterclockwise
and remove the bulb holder.
E145780
5. Remove the bulb from the bulb holder.
Replacing the License Plate Lamp
Bulb
3
2
1
E72789
1. Carefully release the spring clip.
2. Remove the lamp.
3. Remove the bulb.
BULB SPECIFICATION CHART
Replacement bulbs are specified in the
chart below. Headlamp bulbs must be
marked with an authorized “D.O.T.” for
North America to make sure they have the
proper lamp performance, light brightness,
light pattern, and safe visibility. The correct
bulbs will not damage the lamp assembly
or void the lamp assembly warranty and
will provide quality bulb illumination time.
Trade nameFunction
H7LL*Headlamp high beam (Halogen)
H11LL*Headlamp low beam (Halogen)
LED*Side marker lamp - front
263
Fusion/Mondeo (CC7) Canada/United States of America, enUSA, First Printing
Maintenance
